Liquid Flow Battery Stacking and Pressing Production Line

The liquid current battery stacking and press-fitting production line is a key link in the production process of liquid current batteries, and is a highly specialized production line, which involves the stacking and press-fitting process of the battery electrostacks. The line is mainly used for assembling and producing the electrostacks of all-vanadium liquid current batteries.


The assembly line for all-vanadium liquid current battery stack assembly usually includes the pre-processing of various materials such as bipolar plate heat fusion or welding inspection, end plates, insulating plates, current collector plates, bipolar plates, diaphragms, sealing gaskets, or multi-cell batteries, as well as the key links such as the on-board stacking recipe management system. In addition, it also includes core equipment such as servo-hydraulic press for stack assembly, rotary conveyor table, conveyor lifting device, stack tipping mechanism, stack assembly and stacking system, and so on.


Liquid flow battery assembly line includes: small cover plate dispensing inspection/small cover plate welding inspection, bipolar plate sealing line dispensing inspection, end plates, insulating plates, copper electrodes, bipolar plates, diaphragms, sealing gaskets and other types of material stacking pre-processing, equipped with stacking formula management system, with 120T pressure tightening the stack, full-automatic rotary discharging.





  Main  Function

Realization of automatic dispensing, automatic laminating, automatic stacking and automatic inspection units.

With CCD visual inspection and air tightness test function, judgment conditions can be set.

With test results collection, statistics and traceability functions.

High-precision, high-efficiency, high-intelligence production.

Product Advantages

Industry's new generation of professional welding methods; new independent and innovative dispensing alignment system; high-speed stacking applications; closed-loop pressure control and real-time monitoring.
